Power Input: Voltage: AC, 115 volts or 230 volts (external switchĬurrent: 5 Amps max for 120 volts input, 5 Amps max for 230 volts inputįuse Rating: 5 Amp x 250 volts for both 110 volts and 230 volts units (5A Amp Max Fuse 5A 250 VAC +/-Slo-Blo) 64054B-95 * Coverslip Carrier, Product No. 64054W-95 * Vessels and Lids - Black - package of 8, * Product No. * Vessels and Lids - Neutral White - package of 8, * Product No.
Staining Control Microprocessor * Dipping mechanism ON/OFF selectable at all Stations * Available Programs 9 user programmable, 29 steps in each 1 test program * Staining Vessel Capacity 300ml * Available Stations 6 in total, 4 staining/reagent, 1 running water rinse, 1 warm forced-air dry or 6 staining/reagent * Stations * Available Program * Application Time 1 second to 99 minutes, 59 seconds per program step with 29 steps per program * Slide Carrier Capability 20 slides, 3 x 1 inch or optional 30 slide carrier * Coverslip Carrier Capability 20 coverslips, 22 x 22mm * Rinse Station Flow Rate Application range - 500-2000ml/min * Available Options Recirculating Water Bath, Product No.(Temperature adjustable from room temp to 65✬) When the program is complete, the tower moves back to the far left, its Home Position.The Midas®III Stainer gives an audible beep six times to let the operator know that the process is complete. During operation, the tower holding the slide carrier moves from Station to Station according to a programmed sequence.The carrier arm dips the slides by moving up and down automatically every three seconds in the staining vessel.This Dipping Mode can be turned on or off for Stations 1 through 6 by the operator.If Station 5 has been programmed, the auto-rinse feature turns the water on and then off when the staining cycle is complete.If Station 6 has been programmed, the slides are dried with warm air. SYSTEM FUNCTION Specimen slides are loaded into the removable slide carrier, and the carrier is mounted onto the carrier arm of the tower.Stains and fixatives are added to staining vessels and inserted into the Stations on the stainer.
